NA500 Series Optical Auto Level

Professionals face numerous obstacles on the construction site. Whatever the demands of the job, the Leica NA500 levels up. Trust the well-known expertise of Leica Geosystems for the best quality and highest performance. In other words: on the construction site, Leica Geosystems and the Leica NA500 are your best allies for accurate measurements every time.

EXCLUSIVITY. APPROACH. PROTECTION.
Distinctive design and proven technology as a whole
Leica Geosystems knows the construction industry and provides levels for all needs
Subject matter experts and outstanding warranty you can trust, and around the world

MAIN BENEFITS
Quick and accurate measurements
Exclusive design and highest quality results for all grading needs
Manufactured for the most complex works and the most adverse conditions

• Leica Geosystems experts in more than 270 service centers worldwide

First class guarantee

TECHNICAL DATA:
Goggles
Free objective diameter 36 mm
Shortest sighting distance from axis < 1.0 m
Diameter of the field of view at 100 m < 2.1 m
Multiplication constant 100
Addition constant 0

Compensator
Tilt area ± 15’
Setting accuracy (est. deviation) < 0.5''
Spirit level 8' / 2 mm

Horizontal circle
360° graduation
Graduation interval 1°
Weight (net) 1.5kg
Operating temperature range –20°C to +40°C
IP56 protection
